Aichi SR12C - Upper Controls

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒙󱒅󱒒󱒅󱒵󱓆󱓗󱓙󱒅󱒳󱓆󱓒󱓊
18
 UpperControls2.
M085H201
(1) (2) (3) (10)(9) (11)(5) (6) (7)
(8)
(4)
A
(19)(20) (22)
(27)
(21)
(26)
(25)
(24)
(29)(28)
(23)
(12)(13)(14)(15)(16)(17)(18)
A
fig.4‒2
(1) PlatformLevelAdjustSwitch
 Operatethisswitchupand
theplatformlevelwilltiltup.
Operatethisswitchdown
andtheplatformlevelwilltilt
down.
(2) TravelSpeedSelectSwitch
• Select“RABBIT”forahigh
speedtraveling.
• Select“TURTLE”foralow
speedtraveling.
• Select“ELEPHANT”forahigh
torquewhentravelingona
slope.
(3) HornButton
 Pushthehornbuttonand
thealarmhornwillsound.
Releasethehornbuttonand
thealarmhornwillstop.
Beforemovingthemachine,soundthe
horntowarnthepersonnelaroundthe
machine.
(4) Notused
(5) RotatingBeaconSwitch
(Option)
 Turnonthisswitchandthe
rotatingbeaconwilllighton.
(6) WorkLightSwitch(Option)
 Turnonthisswitchandthe
worklightwilllighton.
(7) HeadLightSwitch(Option)
 Turnonthisswitchandthe
headlightwilllighton.
(8) Notused
(9) Notused
(10)EngineStartSwitch/
EmergencyPumpSwitch
• Operatethisswitchupwithout
pressingthefootswitchand
theenginewillstart.
• Holdthisswitchdownto
operatethemachinewith
emergencypump.(Referto
Chapter9fordetails)
(11) EmergencyStopButton
 Pushinthisbuttonto“OFF”
andallfunctionswillstop.Pull
outthisbuttonto“ON”and
themachinewilloperate.
(12)TravelControlLever(Right)
(13)TravelControlLever(Left)
 Operatebothleversup,
andthemachinewilltravel
forward(greendirection).
Operatebothleversdown,andthe
machinewilltravelbackward(red
direction).
 Operateoneoflevers,andthemachine
willpivot.
 Operatebothleversineachopposite
direction,andthemachinewillspin.
(14)BoomElevationControlLever
 Operatethisleverupandthe
boomwillraise.Operatethis
leverdownandtheboomwill
lower.
(15)BoomTelescopeControlLever
 Operatethisleverupandthe
boomwillextend.Operatethis
leverdownandtheboomwill
retract.
(16)BoomRotationControlLever
 Operatethislevertotheleft
andtheboomwillrotate
clockwise.Operatethislever
totherightandtheboomwill
rotatecounterclockwise.
