Aichi SR12C - Boom Operation

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒝󱒅󱒒󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓
37
(2) Forward/Backwardrightturns
M085B301
fig.8‒19
NOTICE
 Ifthedirectionoftravelcannotbe
changedduetoroadsurfaceconditions,
firstadjustthepositionofthemachine
bytravelingforwardorbackward,then
changecourse.
 SpinTurn3‒2‒4
Depressthefootswitchandoperatethetravel
controlleversasshowninthefigurebelow
tomaketheCW(clockwise)orCCWspinturn
(counterclockwise).
M085B401
SpinturnCWSpinturnCCW
fig.8‒20
 BoomOperation3‒3
WARNING
 Makesurethatnopersonorobstacleis
aroundthemachinebeforeoperating
theboom.Theturntableprotrudes
850mmbeyondthewidthofthechassis
whenrotatingtheboom.
 Ifyourvisionispoor,haveaguideto
assistyou.
M0863201
850mm
fig.8‒21
NOTICE
• Beforerotatingtheboom,makesure
therotationlockpinhasbeenunlocked.
• Theboommaynotrotatesmoothly
whenthemachinetilts.
Usethethreecontrolleversfortheboom
elevation,telescopeandrotationtooperate
theboom.
Andusetheflyjibswitchtooperatetheflyjib
elevation.(Ifequipped)
M085F722
FlyJibSwitch
(ifequipped)
BoomRotation
ControlLever
BoomTelescope
ControlLever
BoomElevation
ControlLever
fig.8‒22
 BoomElevating3‒3‒1
Depressthefootswitchand
operatetheboomelevationcontrol
levertoraiseorlowertheboom.
 BoomRotating3‒3‒2
Depressthefootswitchand
operatetheboomrotation
controllevertorotatetheboom.
 BoomTelescoping3‒3‒3
Depressthefootswitchand
operatetheboomtelescope
controllevertoextendorretract
theboom.
 FlyJibElevating(Ifequipped)3‒3‒4
Depressthefootswitchand
operatetheflyjibswitchtoraiseor
lowertheflyjib.
