Aichi SR12C - Traveling

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒝󱒅󱒒󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓
35
NOTICE
 Whenpainting,makesuretoclosethe
coveroftheuppercontrolpanelafter
theplatformhasbeenputinposition,
andkeepthedecalclean.
 FootSwitch3‒1
WARNING
 Donotdisablethefootswitchinany
waye.g.bybinding.
M082Q221
FootSwitch
fig.8‒13
Exceptforthoselistedhere,youmust
depressthefootswitchontheplatformwhile
performingalloperations.
• Enginestart
• Emergencystop(Stoppingtheengine)
• Usingthehorn
• Operatingtheworklight(option)
• Operatingtheheadlight(option)
Traveling3‒2
Usethetravelcontrolleversandthetravel
speedselectswitchtotravelthemachine.
TravelSpeedSelectSwitch
M085F521
Travelcontrollever(Right)
Travelcontrollever(Left)
fig.8‒14
WARNING
• Iftheturntablehasbeenrotated180°,
thetravelingdirectionwillbeopposite
tothelevermovements,sobecareful.
Makesuretocheckthedirectionofthe
arrowonthedecalandonthechassis
whentraveling.
M085D121
Forward
(Green)
Backward
(Red)
Forward
(Green)
Backward
(Red)
fig.8‒15
• Beforetraveling,makesurethatno
personorobstacleisinthetraveling
direction.
CAUTION
• Whentravelingonroughterrainoron
slope,retracttheboomfullyandsetthe
boomunderthehorizontal.
• Whenyoustarttraveling,makesure
toturnthelevergradually,andtostart
slowly.Itisdangeroustostartabruptly.
• Adjustthetravelingspeedbyturning
thetravelcontrollever.
• Allpersonsintheplatformmust
complywithemployer,workarea,and
localandnationalsafetyregulations
regardingtheuseofpersonalprotective
equipment.Alwaysuseasafetyharness
intheplatform.Attachthelanyardto
theauthorizedlanyardanchoragepoint
providedintheplatform.
• Donotchangecourseabruptly.
• Whentraveling,raisetheboomsoitis
almosthorizontal,makesureyoucan
seetothefront,andmakesureyou
travelsafely.
