Aichi SR12C - Chapter 12 Specifications; General Specifications

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒖󱒗󱒅󱒒󱒅󱒸󱓕󱓊󱓈󱓎󱓴󱓈󱓆󱓙󱓎󱓔󱓓󱓘
47
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒖󱒗
Specifications
 GeneralSpecifications1.
Model SR12C SR14CJ
Performance
PlatformHeightMaximum 11.7m 13.6m
HorizontalOutreachMaximum 10.9m 12.7m
PlatformLoadCapacity
(EvenlyDistributed)
6ftPlatform 250kgor2persons+tools:90kg
8ftPlatform 227kgor2persons+tools:67kg
PlatformRotation 180°
TurntableRotation 360°(Continuos)
TurntableTailSwing 850mm
Gradeability(Stowed) 58%(30°)
Max.AllowableTiltAngle 5°
Max.AllowableManualSideForce 400N(41kg)
TurningRadius 0m
Max.AllowableWindSpeed 12.5m/s
Measurements
OverallLength
6ftPlatform 6.86m 7.56m
8ftPlatform 7.02m 7.72m
OverallWidth
6ftPlatform 2.30m
8ftPlatform 2.45m
OverallHeight 1.72m
InsideDiameterof
Platform
6ftPlatform 1.76×0.72×1.1m
8ftPlatform 2.36×0.86×1.1m
GroundClearance 335mm
Weight
GrossWeight 7,675kg 8,510kg
Max.GroundContactPressure 60kPa 65kPa
Powersource
Engine YANMER4TNV88(4CylinderDiesel)
AuxiliaryPowerUnit 12V‒DC
FuelType Dieselfuel(LowsulfurorUltralowsulfur‒limited)
FuelTankCapacity 120L
RecommendedHydraulicOil ShellTellusoilT22
HydraulicTankCapacity 190L
Functionspeed
Elevation
Up 39~51s/-7~70°
Down 39~51s/-7~70°
Telescope
Out 24~36s/6.05m
In 19~31s/6.05m
TurntableRotation(Stowed) 120~150s/360°
FlyJibElevation
Up ‒ 20~30s/-70~60°
Down ‒ 15~25s/-70~60°
PlatformRotation 10~20s/-90~90°
Max.TravelSpeed
(LevelSurface)
Stowed 2.6km/h
Elevated 0.8km/h
* Themachineisdesignedforbothindoorandoutdooruse.
* FortheallowancewhichisnotspecifiedotherwiseisinaccordancewithAICHIʼsownstandards.
* Functionspeedsandgradeabilityassumethereis1persononthemachine.
* Travelspeedandgradeabilitydependsontheconditionofthetravelingsurface.
* Specificationisapproximateanddoesnotincorporatedifferentoptionconfigurations.
* Advisableatmospherictemperaturerange:-20℃~+40℃
