Aichi SR12C - Chapter 4 Part Names; Part names

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒙󱒅󱒒󱒅󱒵󱓆󱓗󱓙󱒅󱒳󱓆󱓒󱓊
17
󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒙
(1) Engine
(2) RotationLockPin
(3) FootSwitch
(4) Platform
(5) RotationGearBox
(6) Turntable
(7) PlatformLevelingCylinder,Lower
(8) LowerControls
(9) FuelTank
(10)HydraulicOilTank
(11) ElevationCylinder
(12)SerialNumberPlate
(13)RotaryActuator
(14)UpperControls
(15)EntryGate
(16)ManualHolder
 Partnames1.
M085H101
(1) (2) (3)
(15)(14)(13)
(17)(18)(16)(18)(19)(20)(21)(22)(23)(24)(25)
(26)
(27)
(16)
(15)(14)(13)
(4)
(6) (7) (8) (9) (10) (11)
(12)
(5)
SR12C
SR14CJ
fig.4‒1
(17)FlyJib(Ifequipped)
(18)PlatformLevelingCylinder,Upper
(19)3
rd
BoomSection
(20)2
nd
BoomSection
(21)1
st
BoomSection
(22)TravelMotor
(23)SwivelJoint
(24)Chassis
(25)Track
(26)IdlerWheel
(27)TurntableBearing
PartNames
