Aichi SR12C - Lower Controls

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒙󱒅󱒒󱒅󱒵󱓆󱓗󱓙󱒅󱒳󱓆󱓒󱓊
20
 LowerControls3.
(17)
(13)
(2)
(9)
(8)
(1) (4) (5) (6) (7)
(10)
(11)
(3)
(12)
(14)
(16)
(15)
M082N302
A
(18)(19) (21)
(26)
(20)
(25)
(24)
(23)(27)
(22)
A
fig.4‒3
(1) BoomElevationSwitch
 Operatethisswitchupandtheboomwill
raise.Operatethisswitchdownandthe
boomwilllower.
(2) BoomRotationSwitch
 Operatethisswitchupandtheboom
willrotatecounterclockwise.Operatethis
switchdownandtheboomwillrotate
clockwise.
(3) BoomTelescopeSwitch
 Operatethisswitchtotheleftandthe
boomwillretract.Operatethisswitchto
therightandtheboomwillextend.
(4) FlyJibSwitch(Ifequipped)
 Operatethisswitchupandtheflyjibwill
raise.Operatethisswitchdownandthefly
jibwilllower.
(5) EmergencyStopButton
 Pushinthisbuttonto“OFF”
andallfunctionswillstop.Pull
outthisbuttonto“ON”and
themachinewilloperate.
(6) PlatformRotationSwitch
 Operatethisswitchupandtheplatform
willrotatecounterclockwise.Operatethis
switchdownandtheplatformwillrotate
clockwise.
(7) PlatformLevelAdjustSwitch
 Operatethisswitchupandtheplatform
levelwilltiltup.Operatethisswitchdown
andtheplatformlevelwilltiltdown.
(8) Pre-startCheckSwitch
 Followtheinstructionand
holdthisswitchupwhenthe
pre-startcheckisperformed.
(9) Notuse
(10)RotatingBeaconSwitch
(Option)
 Turnonthisswitchandthe
rotatingbeaconwilllighton.
(11) Notuse
(12)FunctionSpeedSelectSwitch
• Select“RABBIT”forahigh
speedfunction.
• Select“TURTLE”foralow
speedfunction.
(13)EngineStartSwitch/
EmergencyPumpSwitch
• Operatethisswitchupwithout
operatingtheenableswitch
andtheenginewillstart.
• Holdthisswitchdownto
operatethemachinewith
emergencypump.(Referto
Chapter9fordetails)
(14)KeySwitchforUpperControl/
Off/LowerControlSelection
 Turnthekeyswitchtotheleft
andtheuppercontrolswill
operate.
 Turnthekeyswitchtocenter
positionandthemachinewill
beoff.
 Turnthekeyswitchtothe
rightandthelowercontrols
willoperate.
(15)FuseHolder
(16)HourMeter
 Thehourmeterworksonlywhenthe
engineisinmotion.
