21
(17)EnableSwitch
 Holdthisswitchupto
operatethemachineonthe
ground.
 Theenableswitchis
canceledifanyofboom,flyjib(if
equipped)andplatformfunctionisnot
operatemorethan20secondsafter
holdinguptheenableswitchto“ON,”
thenthepowerindicatorlightblinks.
Releasetheswitchonceandthepower
indicatorlightturnson,thenoperateagain
toenablethefunctions.
(18)FuelLevelLight
 Thislightgoesonwhenthe
fuellevelislow.Refillthefuel.
(19)OverloadWarningLight
 Whentheplatformis
overloaded,thislightblinks,
thealarmbuzzersounds
andallofthefunctionsare
disabled.
(20)Notused
(21)TiltLight
 Thislightgoesonandthe
alarmbuzzersoundswhen
themachinetiltsmorethan
max.allowabletiltangle.
(22)SystemFailureLight
 Thislightgoesonorblinks
intheeventofacomputer
controlsystemfailure.
CAUTION
 Stopusingthemachineandcontact
AICHIorAICHIʼsdealerforinspections,
ifthislightgoesonorblinks.
(23)AirFilterClogLight
 Thislightgoesonwhentheair
filterisclogged.
 Ifthislightgoesonwhilethe
engineisinmotion,cleanor
replacetheairfilterelement.
(24)ChargeLight
 Afterstartingtheengine,this
lightgoesoff.
 Ifthislightgoesonwhilethe
engineisinmotion,checkthecharging
system,e.g.alternatorandfanbelt.
(25)WaterTemperatureLight
 Whentheenginecooling
watertemperaturegoesup
abnormally,theenginestops
andthislightgoesonto
protecttheenginefromoverheat.
CAUTION
 Ifthislightgoesonduringoperations,
stopusingthemachineandcheckthe
enginecoolingsystem,e.g.,shortageof
coolingwaterandbrokenfanbelt.
DANGER
 Whentheengineisoverheated,donot
removetheradiatorcap,astheheated
waterwillsplashout,resultinginscald.
(26)OilPressureLight
 Afterstartingtheengine,
thislightgoesoff.Checkthe
enginelubricationsystem,
e.g.,shortageofengineoil,
ifthislightgoesonwhiletheengineisin
motion.
(27)PreheatLight
 Thislightgoesonwhen
thekeyswitchisturnedto
“LOWERCONTROL”or“UPPER
CONTROL”andgoesoffwhen
thepreheatingiscompleted.
