Aichi SR12C - Tie Down; Hoisting the Machine

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒖󱒕󱒅󱒒󱒅󱒹󱓗󱓆󱓓󱓘󱓕󱓔󱓗󱓙󱓎󱓓󱓌󱒅󱒲󱓊󱓙󱓍󱓔󱓉
44
 TieDown2.
󱒸󱓙󱓊󱓕󱒅󱒖
 Tiedownthechassis
ofthemachinetothe
transportvehiclebed
securely.Placepadson
thecrawlertrackstoprotectit.(fig.10‒2,A)
M0858203
A
A
fig.10‒2
󱒸󱓙󱓊󱓕󱒅󱒗
 Tiedowntheboomandplatformsothat
itisnotswungduringthetransportation.
Atthistime,besuretoallowtheclearance
betweenthebottomoftheplatformandthe
transportvehiclebed.
 Ifequippedwiththeflyjib,tiedownthe
platformwithplacingawoodblockunder
theplatformtopreventtheplatformfrom
bouncingduringthetransportation.
M0858321
Ifequipped
withtheflyjib
Woodblock
Tiedownrings Tiedownrings
Clearance
Clearance
※
※
※
※※
※
fig.10‒3
NOTICE
 Donottightenthetiedownchains
orwireropesmarked“※”toomuch.
Tightenthemjustsothattheplatform
isnotswungorbouncedduringthe
transportation.
 HoistingtheMachine3.
WARNING
• Donotallowanypersontogetunder
themachinewhilehoisting.
• Donotpasstheslingchainsorwire
ropesexceptdesignatedrings.
• Failuretoheedwarningscouldresult
inbreaking,falling,orotherhazards
leadingtodeathorseriousinjury.
󱒸󱓙󱓊󱓕󱒅󱒖
 Retractandlowertheboomfully,and
positiontheflyjibtohorizontalifequipped.
󱒸󱓙󱓊󱓕󱒅󱒗
 Passtheslingchainsorwire
ropesthroughthehoistingrings
locatedontheturntableas
showninthefig.10‒4.
󱒸󱓙󱓊󱓕󱒅󱒘
 Adjusttheriggingtopreventdamagetothe
machineandtokeepthemachinelevel.
M0858420
1400mm
1400mm
Ifequipped
withtheflyjib
fig.10‒4
