Aichi SR12C - Starting from Platform

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒝󱒅󱒒󱒅󱒴󱓕󱓊󱓗󱓆󱓙󱓎󱓔󱓓
33
M082L722
FuelLevelLight
fig.8‒6
NOTICE
 Thecapacityofthefueltankis120liters.
 StartingfromPlatform1‒2
Dothefollowingtostarttheenginefromthe
uppercontrols.
󱒸󱓙󱓊󱓕󱒅󱒖
 Turnthekeyswitchto“UPPER
CONTROL,”andthen,makesure
theenginefailurelightgoeson.
NOTICE
• Enginefailurelight
Aftertheenginestarts,
rotationswillincrease,and
theenginefailurelightwill
gooff.Ifitlightswhile
traveling,thereisanengine-related
problem.
• Concerningengine-relatedproblems,
thedefectivepartcanbeidentified
usingtheindicatorlightsonthelower
panel.Refertosection1‒1fordetails.
󱒸󱓙󱓊󱓕󱒅󱒗
 Operatetheenginestartswitch
upto“ENGINESTART”without
depressingthefootswitchto
starttheengine.
 Immediatelyreleaseyourhand
fromtheenginestartswitchoncetheengine
hasstarted.
M085F321
EngineStartSwitch
fig.8‒7
NOTICE
• Donotholdtheenginestartswitch
upfor15secondsormore.Failure
toreleaseyourhandcouldresultin
damagetothestartermotor.
• Taketheintervalof30secondsormore
beforere-startingtheenginetoprevent
damagingtheengine.
󱒸󱓙󱓊󱓕󱒅󱒘
 Afterstartingengine,idletheenginefor
about5minutesforwarmingup.
NOTICE
 Iftheoutsideairtemperatureisbelow
thetemperaturerangeforthehydraulic
oilusedinthemachine,travelthe
machineinawarmplaceuntilthe
hydraulicoiliswarmenough,andthen
dotheoutsidework.
󱒸󱓙󱓊󱓕󱒅󱒙
 Checkthefuellevellight.
 Whenthereislittlefuel
remaining,thislightwillbelit.
Onalevelsurface,itlightsat
about30liters.
 Ifthefuellevellightison,addfuel(Referto
Chapter12fordetails).
M085F221
FuelLevelLight
fig.8‒8
