19
(17)PlatformRotationSwitch
 Operatethisswitchtothe
leftandtheplatformwill
rotateclockwise.Operate
thisswitchtotherightand
theplatformwillrotatecounterclockwise.
(18)FlyJibSwitch(Ifequipped)
 Operatethisswitchupand
theflyjibwillraise.Operate
thisswitchdownandthefly
jibwilllower.
(19)Notused
(20)SystemFailureLight
 Thislightwillgoonorblink
intheeventofacomputer
controlsystemfailure.
CAUTION
 Stopusingthemachineandcontact
AICHIorAICHIʼsdealerforinspections,
ifthislightgoesonorblinks.
(21)FuelLevelLight
 Thislightwillgoonwhenthe
fuellevelislow.Refillthefuel.
(22)EngineFailureLight
 Thislightwillgooninthe
eventofanenginefailure,
e.g.,failedchargingsystem,
abnormallylowoilpressure,
andabnormallyhighcooling
watertemperature.Checktheindicator
lightsonthelowercontrolstoidentifythe
cause.
(23)PowerIndicatorLight
 Thislightwillgoonwhen
thekeyswitchonthelower
controlsturnsto“UPPER
CONTROL.”
(24)Notused
(25)TiltLight
 Thislightwillgoonandthe
alarmbuzzerwillsoundwhen
themachinetiltsmorethan
maxallowabletiltangle.
(26)Notused
(27)OverloadWarningLight
 Whentheplatformis
overloaded,thislightwill
blink,thealarmbuzzer
willsoundandallofthe
functionswillbedisabled.
(28)Notused
(29)FootSwitch
 Depressthisswitchtooperatethe
machineontheplatform.
 Thefootswitchiscanceledifanyofboom,
flyjib(ifequipped),platformandtraveling
functionisnotoperatedmorethan20
secondsafterdepressingthefootswitch,
thenthepowerindicatorlightblinks.
Releasetheswitchonceandthepower
indicatorlightturnson,thenoperateagain
toenablethefunctions.
