Aiphone IS SERIES Setting Manual

7
GETTING STARTED USING THE SYSTEM APPENDIX
SETTING THE SYSTEM
Title Sub title Item Sub item Setting range Default
System setting Advanced station
settings
Master station Stations to be scan monitored (Select up to 20 sub stations from the
registered ones.)
-
Other
Master station function:
paging, chime, monitor,
door release, and
remote site call
ON/OFF ON
Central
control unit
Contact input
(Contact input) S1 to S4 S1
Contact type
Normally open (NO)
/Normally closed (NC)
Normally open
(NO)
Trigger condition None/Broadcast chime/Stop chime None
Sound source
(Only when "Broadcast
chime" is selected at
"Trigger condition")
Internal sound source (Select a
sound fi le or sequence name from
the registered ones in the list.)
/External sound source (Select either
External sound source 1 or 2.)
-
Chime priority
(Only when "Broadcast
chime" is selected for
"Trigger condition")
Normal/Priority/Urgent Normal
Zone name
(Only when "Broadcast
chime" is selected at
"Trigger condition")
(Select from the registered ones.) -
Contact output
(Contact output
terminal)
L1 to L8 L1
Contact type
Normally open (NO)
/Normally closed (NC)
Normally open
(NO)
Trigger condition None/Calling notice/Door release
/External sound source/PA output
None
Calling notice
(Only when "Calling
notice" is selected at
"Trigger condition")
Normal: OFF/ON
Priority: OFF/ON
Urgent: OFF/ON
Normal: OFF
Priority: OFF
Urgent: OFF
Door release
(Only when "Door
release" is selected at
"Trigger condition")
(Select from the sub stations
registered and set for the central
control unit.)
-
External sound source
(Only when "External
sound source" is
selected at "Trigger
condition")
External sound source 1
/External sound source 2
-
PA output
(Only when "PA output"
is selected at "Trigger
condition")
PA output 1 to 4 -
Room sub
control unit/
Add-on
control unit
Contact output
(Contact output
terminal)
L1 to L4 L1
Contact type
Normally open (NO)/Normally closed
(NC)
Normally open
(NO)
Trigger condition None/Calling notice/Door release/PA
output
None
Calling notice
(Only when "Calling
notice" is selected at
"Trigger condition")
Normal: OFF/ON
Priority: OFF/ON
Urgent: OFF/ON
Normal: OFF
Priority: OFF
Urgent: OFF
Door release
(Only when "Door
release" is selected at
"Trigger condition")
(Select from the sub stations
registered and set for each control
unit.)
-
PA output
(Only when "PA output"
is selected at "Trigger
condition")
PA output 1 to 4 -
Zone setting Zone number - (Select from the registered ones.) -
Stations - (Select from the list.) -
PA output - (Select from the list.) -
