Airo A Series - 11 Wiring Diagram

Use and Maintenance Manual – A12 JE A15 JE A17 JE A12 JED A15 JED
Series
Page 101
11. WIRING DIAGRAM
SYMB.
DESCRIPTION
Pag-Col.
AV1
GROUND AUDIBLE ALARM
2-26
AV2
PLATFORM AUDIBLE ALARM
6-105
AVS
BEEPER + BEACON FOR AIRO SENTINEL
5-80/82
BC1
BATTERY CHARGER 1
1-10
BC2
BATTERY CHARGER 2
1-12
BT
BATTERY
1-15
BY
OVERLOAD CONTROLLER BY-PASS SELECTOR
6-113
CNV
CONVERTER 48VDC-12VDC
1-15
EV4
LOWER BOOM LIFTING SOLENOID VALVE
3-47
EV5
LOWER BOOM LOWERING SOLENOID VALVE
3-48
EV6
TELESCOPIC BOOM EXTENSION SOLENOID VALVE
3-49
EV7
TELESCOPIC BOOM RETRACTION SOLENOID VALVE
3-45
EV8
RIGHT STEERING SOLENOID VALVE
3-54
EV9
LEFT STEERING SOLENOID VALVE
3-54
EV11A
ON-OFF CIRCUIT ENABLE SOLENOID VALVE
3-50
EV11B
PROPORTIONAL CIRCUIT ENABLE SOLENOID VALVE
3-50
EV12
CLOCKWISE TURRET ROTATION SOLENOID VALVE
3-49
EV13
ANTICLOCKWISE TURRET ROTATION SOLENOID VALVE
3-48
EV14
UPPER BOOM LIFTING SOLENOID VALVE
3-50
EV15
UPPER BOOM LOWERING SOLENOID VALVE
3-51
EV16
HIGH CAGE LEVELLING SOLENOID VALVE
3-45
EV17
LOW CAGE LEVELLING SOLENOID VALVE
3-47
EV18
JIB LIFTING SOLENOID VALVE
3-55
EV19
JIB LOWERING SOLENOID VALVE
3-55
EV21
CLOCKWISE CAGE ROTATION SOLENOID VALVE
3-53
EV22
LEFT CAGE ROTATION SOLENOID VALVE
3-52
EV29
POT-HOLE GUARD LOWERING SOLENOID VALVE
5-83
EV30
POT-HOLE GUARD LIFTING SOLENOID VALVE
5-84
EV32
CLOCKWISE JIB ROTATION SOLENOID VALVE (OPTIONAL)
3-56
EV33
ANTICLOCKWISE JIB ROTATION SOLENOID VALVE (OPTIONAL)
3-53
EV40
BRAKE RELEASE SOLENOID VALVE
3-51
EV41A
OSCILLATING AXLE UNLOCK SOLENOID VALVE (OPTIONAL)
5-85
EV41B
OSCILLATING AXLE UNLOCK SOLENOID VALVE (OPTIONAL)
5-86
F1
CONTROL CIRCUIT FUSE
1-16
F2
CONVERTER CIRCUIT FUSE
1-13
F3
INVERTER AUXILIARY SYSTEM FUSE
1-16
F4
INTERFACE BOARD FUSE
1-16
FO
FACTORY OVERRIDE
2-25
GRF1
ROTATING BEACON 1
5-86
GRF2
ROTATING BEACON 2
5-86
GRF3
ROTATING BEACON 3
5-87
KL
HORN 48VDC
5-81
LC
LINE REMOTE SWITCH
1-06
LCBL
LEFT BATTERY CHARGER LED
2-33
LCBR
RIGHT BATTERY CHARGER LED
2-33
M1A
I BOOM POSITION END STOP
5-89/90
M1B
II BOOM POSITION END STOP
5-90/91
M1C
JIB POSITION END STOP
5-91/92
M1E
TELESCOPIC BOOM POSITION END STOP
5-92/93
M1S
DRIVE LIMIT SWITCH (OPTIONAL)
5-93
M2A
CLOCKWISE TURRET ROTATION STOP LIMIT SWITCH
4-64
M2B
ANTICLOCKWISE TURRET ROTATION STOP LIMIT SWITCH
4-65
MPT1
RIGHT POT-HOLE GUARD LIMIT SWITCH
4-65
MPT2
LEFT POT-HOLE GUARD LIMIT SWITCH
4-66
MPT1A
RIGHT LIMIT SWITCH A, SMART POT-HOLE GUARDS
4-71
MPT1B
RIGHT LIMIT SWITCH B, SMART POT-HOLE GUARDS
4-71
MPT2A
LEFT LIMIT SWITCH A, SMART POT-HOLE GUARDS
4-72
MPT2B
LEFT LIMIT SWITCH B, SMART POT-HOLE GUARDS
4-72
PS1A
PROXIMITY SENSOR A, TURRET POSITION
4-74/75
PS1B
PROXIMITY SENSOR B, TURRET POSITION
4-75/76
RBC
BATTERY CHARGER RELAY
1-11/13
SP0
POWER CIRCUIT EMERGENCY SWITCH
1-15
SP1
EMERGENCY SWITCH – ON THE GROUND
2-23/24
