Airo A Series - Model A17 JE

Use and Maintenance Manual – A12 JE A15 JE A17 JE A12 JED A15 JED Series
Page 18
2.3. Model A17 JE.
A17 JE
Dimensions:
Maximum working height
17,1
m
56‘ 2”
ft
Max. platform height
15,1
m
49‘ 5”
ft
Ground clearance (with pot-hole guards lifted)
135
mm
5‘ 3”
in
Ground clearance - with pot-hole guards down - machine with fixed
jib
50
mm
2”
in
Ground clearance - with pot-hole guards down - machine with
rotating jib
25
mm
1”
in
Max. outreach from turntable centre
8,9
m
29‘ 3”
ft
Turret rotation (not continuous)
370
°
370
°
Platform rotation
180
°
180
°
Jib rotation (optional)
130
°
130
°
Platform height for safety speed activation
< 3,5
m
< 11‘ 5”
ft
Internal steering radius
0,9
m
2‘ 11”
ft
External steering radius
3,0
m
9‘ 10”
ft
Maximum load - machine with fixed jib (m)
230
Kg
500
lbs
Max. number of people on the platform (n) – indoors
2
2
Tool and material weight (me) (**) – indoors
70
Kg
154
lbs
Max. number of people on the platform (n) – outdoors
2
2
Tool and material weight (me) ** – outdoors
70
Kg
154
lbs
Maximum load - machine with rotating jib optional (m)
230
Kg
500
lbs
Max. number of people on the platform (n) – indoors
2
2
Tool and material weight (me) (**) – indoors
70
Kg
154
lbs
Max. number of people on the platform (n) – outdoors
1
1
Tool and material weight (me) ** – outdoors
150
Kg
330
lbs
Max. height / outreach drive - machine with fixed jib
Max / Max
Max / Max
Max. height / outreach traction - machine with rotating jib
16,8 / 8,6
m
55’ 1” / 28’ 2”
ft
Maximum dimensions of platform (*****)
0.8 x 1.4
m
2‘ 7” x 4’ 7”
ft
Max. hydraulic pressure
250
Bar
3626
psi
Tyre dimensions (****)
Ø 600 x 190
mm
23‘ 6” x 7‘ 4”
in
Tyre type (****)
Cushion soft
Cushion soft
Transport dimensions
6,4 x 1,5
H=1,99
m
21’ x 4‘ 11”
h= 6’ 1”
ft
Transport dimensions with retracted jib
6,0 x 1,5
h = 2,4
m
19’ 7” x 4’ 11”
h =7’ 11”
ft
Machine weight (unloaded) - machine with rotating jib (*)
8305
Kg
18310
lbs
Machine weight unloaded - machine with rotating jib (*)
8375
Kg
18460
lbs
Stability limit:
Longitudinal inclination (compared to the extensible structure)
2
°
2
°
Transversal inclination (compared to the extensible structure)
3
°
3
°
Maximum manual force - indoors
400
N
90
lbf
Maximum manual force - outdoors - machine with fixed jib
400
N
90
lbf
Maximum manual force - outdoors - machine with rotating jib
200
N
45
lbf
Maximum wind speed (***)
12,5
m/s
28
mph
Max. load per wheel
3800
Kg
8380
lbs
