Use and Maintenance Manual – A12 JE A15 JE A17 JE A12 JED A15 JED Series
Page 19
Performance:
Driving wheels
2
2
Max. drive speed
6
km/h
4
mph
Safety drive speed
0,6
km/h
0,4
mph
Oil tank capacity
60
Lt.
16
gal
Gradeability
25
%
25
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-15
°C
5
°F
Battery power
Standard battery voltage and capacity - drive battery
48 / 385
V/Ah
48 / 385
V/Ah
Total electrolyte quantity of standard battery
24 x 6.1
Lt.
24 x 2
gal
Standard battery weight
564
Kg
1243
lbs
Single-phase battery charger (HF)
48 / 45
V/A
48 / 45
V/A
Battery charger power supply mains voltage - single phase
230 - 50
V - Hz
230 – 50
V – Hz
Max. current absorbed by battery charger
15
A
15
A
Max. installed power
15
kW
20
hp
AC electric pump power
9
kW
12
hp
Max. absorbed current
210
A
210
A
AC drive motors power
2 x 3
kW
2 x 4
hp
Max. current absorbed by each motor
2 x 60
A
2 x 60
A
380V three-phase electrical pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
230V single-phase electric pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
(*) In some cases, different limits can be fixed. It is recommended to comply with the data shown on the machine plate.
(**) me = m – (n x 80).
(***) Wind speeds higher or equal to 12.5 m/s indicate that the machines can also be used outdoors; Wind speeds equal to 0 m/s indicate that the machines can
be used INDOORS ONLY.
(****) Cushion Soft no-marking standard tyres.
(*****) Standard steel platform 800x1400 mm; Optional steel platform 800x1150 mm.
