Airo A Series - Model A15 JE

Use and Maintenance Manual – A12 JE A15 JE A17 JE A12 JED A15 JED Series
Page 15
2.2. Model A15 JE
A15 JE
Dimensions:
Maximum working height
15.0
m
49’ 2”
ft
Max. platform height
13.0
m
42’ 7”
ft
Ground clearance (with pot-hole guards lifted)
135
mm
5’ 3”
in
Ground clearance (with pot-hole guards lowered)
25
mm
0’ 9”
in
Max. outreach from turntable centre
8.95
m
29’ 4”
ft
Turret rotation (not continuous)
370
°
370
°
Platform rotation
180
°
180
°
Jib rotation (optional)
130
°
130
°
Platform height for safety speed activation
< 3.5
m
11’ 5”
ft
Internal steering radius
0.9
m
2’ 11”
ft
External steering radius
3.0
m
9’ 10”
ft
Maximum capacity (m)
230
Kg
500
lbs
Max. number of people on the platform (n) – indoors
2
2
Tool and material weight (me) (**) – indoors
70
Kg
154
lbs
Max. number of people on the platform (n) – outdoors
2
2
Tool and material weight (me) ** – outdoors
70
Kg
154
lbs
Maximum drive height
Max
Max
Maximum dimensions of platform (*****)
0.8 x 1.4
m
2‘ 7” x 4’ 7”
ft
Max. hydraulic pressure
250
Bar
3626
psi
Tyre dimensions (****)
Ø 600 x 190
mm
23’ 6” x 7’ 4”
in
Tyre type (****)
Cushion soft
Cushion soft
Transport dimensions
6,5 x 1,5
H=1,99
m
21’ 3”x 4’ 11” x
6’ 6”
ft
Transport dimensions with rotated platform
6,2 x 1,5
H=1,99
m
20’ 4”x 4’ 11” x
6’ 6”
ft
Transport dimensions with retracted jib
4,9 x 1,5 H=2,6
m
16’ 1”x 4’ 11” x
8’ 6”
ft
Transport dimensions with retracted jib and rotated platform
4,9 x 1,5 H=2,2
m
16’ 1”x 4’ 11” x
7’ 2”
ft
Machine weight (unloaded) (*)
7490
Kg
16500
lbs
Stability limit:
Longitudinal inclination
3
°
3
°
Transversal inclination
3
°
3
°
Maximum manual force - indoors
400
N
90
lbf
Maximum manual force - outdoors
400
N
90
lbf
Maximum wind speed (***)
12.5
m/s
28
mph
Max. load per wheel
3400
Kg
7500
lbs
Performance:
Driving wheels
2
N
2
N
Max. drive speed
6
km/h
4
mph
Safety drive speed
0,6
km/h
0,4
mph
Oil tank capacity
60
Lt.
16
gal
Gradeability
25
%
25
%
Max. operating temperature
+50
°C
122
°F
Min. operating temperature
-15
°C
5
°F
