Use and Maintenance Manual – A12 JE A15 JE A17 JE A12 JED A15 JED Series
Page 25
Battery power
Voltage and standard battery capacity - Deep Cycle
48 / 320
V/Ah
48 / 320
V/Ah
Total electrolyte quantity of standard battery
8 x 11,4
Lt.
8 x 3
gal
Standard battery weight
8 x 52
Kg
8 x 115
lbs
Voltage and optional battery capacity - Drive Battery
48 / 330
V/Ah
48 / 330
V/Ah
Total electrolyte quantity of optional battery
24 x 4,4
Lt.
6 x 1
gal
Optional battery weight
410
Kg
904
lbs
Voltage and optional battery capacity - Drive Battery
48 / 385
V/Ah
48 / 385
V/Ah
Total electrolyte quantity of optional battery
24 x 6,1
Lt.
24 x 2
gal
Optional battery weight
564
Kg
1243
lbs
Single-phase battery charger (HF)
48 / 45
V/A
48 / 45
V/A
Battery charger power supply mains voltage - single
phase
230 - 50
V - Hz
230 – 50
V -
Hz
Max. current absorbed by battery charger
15
A
15
A
Max. installed power
15
kW
20
hp
AC electric pump power
9
kW
12
hp
Max. absorbed current
210
A
210
A
AC drive motors power
2 x 3
kW
2 x 4
hp
Max. current absorbed by each motor
2 x 60
A
2 x 60
A
Motor generator
Diesel engine type
HATZ 1B30/6
Max. motor power
5
kW
7
hp
Adjusted Power
4,6
kW
6
hp
Generator power
2,4
kW
3
hp
Supplied voltage
48
VDC
48
VDC
Supplied current
50
A
50
A
380V three-phase electrical pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
230V single-phase electric pump (optional)
Motor power
NA
kW
NA
hp
Max. absorbed current
NA
A
NA
A
Max. drive speed
NA
km/h
NA
mph
(*) In some cases, different limits can be fixed. It is recommended to comply with the data shown on the machine plate.
(**) me = m – (n x 80).
(***) Wind speeds higher or equal to 12.5 m/s indicate that the machines can also be used outdoors; Wind speeds equal to 0 m/s indicate that the machines can
be used INDOORS ONLY.
(****) Standard tyres: cushion soft no-marking.
(*****) Standard steel platform 800x1400 mm; Optional steel platform 800x1150 mm.
