A)
Drive proportional joystick control
B)
Proportional lever control pantograph up/down
C)
Proportional lever control boom up/down
D)
Proportional lever control jib up/down
E)
Proportional lever control telescopic boom out/in
F)
Proportional lever control QUICK UP/QUICK DOWN (OPTIONAL)
G)
Proportional lever control turret rotation
H)
Proportional lever control jib rotation (OPTIONAL)
I)
Platform rotation switch
L)
Platform level switch
Q)
Motor generator start/stop button (models A12 JED - A15 JED)
R)
Emergency STOP button
S)
Manual horn
T)
Drive speed selector
V)
Right steering switch
Z)
Left steering switch
ZA)
Enabled control panel warning light
ZB)
Flat battery warning light
ZC)
Drive controller fault warning light / Diesel motor generator fault / low fuel level warning light (OPTIONAL)
ZD)
Danger warning light
ZE)
Overload warning light
ZF)
Dead-man pedal
ZG)
Motor generator Automatic / Manual operation mode selector (models JED12 - A15 JED)
All movements (except for platform rotation and platform level compensation) are controlled by proportional joystick /levers; it is
therefore possible to adjust movement speed by means of the relative controls. To avoid sudden shakes during movements, it is
advisable to operate the proportional joystick controls gradually.
For safety reasons, to operate the machine, it is necessary to press the “dead-man” ZF pedal on the platform. If the “dead-man”
pedal is accidentally released while the machine is operating, the movement is immediately stopped.
WARNING!
Holding down the “dead-man” pedal for over 10 seconds without carrying out any operation will disable the
control panel.
The disabled control panel condition is indicated by the flashing green led (ZA). To operate the machine
again it is necessary to release the “dead-man” pedal and press it again; the green led (ZA) will light up
steady and for the next 10 seconds all controls will be enabled.
