Component Video Output
Io XT features a group of 3 BNC connectors for output of component, composite
and Y/C functions. The signals are labeled on the BNC connectors on the rear
panel of Io XT.
NOTE: Component Video, or YPbPr, has been given several names over time. YUV,
Y/R-Y/B-Y, and YCbCr, are just some examples. Although these various formats
have some differences in levels, they are all basically the same. Io XT uses the
modern YPbPr terminology exclusively. Io XT supports three different types of
YPbPr: SMPTE/EBU N10, Betacam (NTSC), and Betacam (NTSC Japan). These three
formats differ in level only and are configured via the AJA Control Panel.
Io 4K Connectors
These connectors are offered only on the Io 4K model.
Thunderbolt 2 Ports
The Io 4K provides the second-generation Thunderbolt ports to support
UltraHD and 4K signals. Two ports are provided for “daisy-chained” network
configurations.
See https://www.aja.com/solutions/thunderbolt for more information about
Thunderbolt.
Bi-directional SDI I/O
Four bidirectional BNC connectors can be configured via the AJA Control Panel
for:
• HD/SD inputs (x2) and outputs (x2)
• Or you can input or output 4 channels of video representing individual
quadrants of the higher denition UltraHD (3840x2160) and 4K (4096x2160)
formats.
NOTE: The Io 4K can only be configured for either input or output of UltraHD or 4K at a
time. It cannot support input and output at the same time since both require four
BNCs.
Dedicated SDI HD/SD Output
NOTE: One BNC connector is provided for full-time, real-time output of HD/SD video. 4K
video is down-converted to 2K HD and UltraHD is down-converted to HD.
Installing Io XT/4K Software
NOTE: Always uninstall previous versions of KONA software before updating your
software.
Download
Go to the AJA website and download the latest Io XT/4K driver software
containing the AJA Control Panel application:
https://www.aja.com/en/support/downloads/
System software updates may occasionally become available to AJA Io XT/4K
owners on our website (www.aja.com). We recommend checking occasionally for
both software updates and additional product information.
