Akuvox R20A Admin Guide

59
● Password: enter the password for the HTTP command. For example:
“12345”.
Please refer to the following example:
http://192.168.35.127/fcgi/do?
action=OpenDoor&UserName=admin&Password=12345&DoorNum=1
15.7.Configure Exit Button for Door Unlock
When you need to open the door from inside using the Exit button installed by
the door, you can configure the door phone Input to trigger the relay for the door
access on web Intercom > Input interface.
Parameter set-up:
● Enabled: enable the function if needed.
● Trigger Electrical Level: select the trigger electrical level options between
Note:
● DoorNum in the HTTP command above refers to the relay number
#1 to be triggered for the door access.
AKUVOX SMART INTERCOM www.akuvox.com

Akuvox R20A Specifications

General

Audio	Built-in Microphone and Speaker
Installation	Wall-mounted
Ingress Protection	IP65
Card Reader	13.56MHz, Mifare
RS485	Yes
Camera	2MP
Network	10/100Mbps Ethernet
Protocols	SIP
Power	PoE or 12V DC
PoE	IEEE 802.3af
Relays	1
Input	2
