Akuvox R20A Admin Guide

89
Note:
Server Address format:
● TFTP: tftp://192.168.0.19/
● FTP: ftp://192.168.0.19/ (allows anonymous login)
ftp://username:password@192.168.0.19/(requires a user name
and password)
● HTTP: http://192.168.0.19/ (use the default port 80)
http://192.168.0.19:8080/ (use other ports, such as 8080)
● HTTPS: https://192.168.0.19/ (use the default port 443)
Note:
● Akuvox do not provide user specified server.
● Please prepare TFTP/FTP/HTTP/HTTPS server by yourself.
AKUVOX SMART INTERCOM www.akuvox.com

Akuvox R20A Specifications

General

Audio	Built-in Microphone and Speaker
Installation	Wall-mounted
Ingress Protection	IP65
Card Reader	13.56MHz, Mifare
RS485	Yes
Camera	2MP
Network	10/100Mbps Ethernet
Protocols	SIP
Power	PoE or 12V DC
PoE	IEEE 802.3af
Relays	1
Input	2
