Akuvox SP-R5xP User Manual

Administrator’s Guide for Akuvox SP-R5xP IP Phones
Akuvox Proprietary and Confidential. Copyright © 2014 Akuvox network Co., Ltd..
Page 64 of 221
them. IP phones only support one area code rule.
Procedure
Area code rule can be configured using the configuration files or locally.
Configuration File <r0000000000xx>.conf/<MAC>.conf
Create the area code rule and specify the
maximum and minimum lengths of entered
numbers.
Local Web User Interface
Create the area code rule and specify the
maximum and minimum lengths of entered
numbers.
Navigate to:
http://<phoneIPAddress>/fcgi/do?id=4&id=7
To configure an area code rule via web user interface:
1. Click on Phone > Dial Plan
2. On Area Code, enter the desired code in the Code field
3. Enter the desired min length (1~15) in Min length field
4. Enter the desired max length (1~15) in Max length field
5. Select the desired account from the pull-down list of Account
6. Click on Submit to submit the change
Hotline
Hotline allows the IP phone to dial out the hotline number automatically by the first available
line after a specified time interval when off-hook. It is a point-to-point communication link in
which a call is automatically directed to the preset hotline number. IP phones only support
one hotline number.

Akuvox SP-R5xP Specifications

General

Brand	Akuvox
Model	SP-R5xP
Category	IP Phone
Language	English
