Akuvox SP-R5xP User Manual

Administrator’s Guide for Akuvox SP-R5xP IP Phones
Akuvox Proprietary and Confidential. Copyright © 2014 Akuvox network Co., Ltd..
Page 75 of 221
Procedure
Anonymous call rejection can be configured using the configuration files or locally.
Configuration File <r0000000000xx>.conf/<MAC>.conf Configure anonymous call rejection.
Local Web User Interface
Configure anonymous call rejection.
Navigate to:
http://<phoneIPAddress>/fcgi/do?id=3&id=2
To configure anonymous call rejection via web user interface:
1. Click on Account > Advanced
2. On Call, select the desired value from the pull-down list of Anonymous Call Rejection
3. Click Submit the accept the changes
Do Not Disturb
If a user activate Do Not Disturb (DND), it will prevent all calls. DND can be activated or
deactivated via DNA soft key. In addition, the DND on code and DND off code are used to
activate/deactivate the server-side DND feature. They may vary according to different servers.
Return Message When DND
This feature defines the return code and the reason of the SIP response message for the
rejected incoming call when DND is enabled on the IP phone. The caller’s phone LCD screen

Akuvox SP-R5xP Specifications

General

Brand	Akuvox
Model	SP-R5xP
Category	IP Phone
Language	English
