Akuvox SP-R5xP User Manual

Administrator’s Guide for Akuvox SP-R5xP IP Phones
Akuvox Proprietary and Confidential. Copyright © 2014 Akuvox network Co., Ltd..
Page 77 of 221
displayed on the caller’s phone LCD screen.
Available return codes and reasons are:
 404 (Not Found)
 480 (Temporarily not available)
 486 (Bust here)
Procedure
Return code for refused call can be configured using the configuration files or locally.
Configuration File <r0000000000xx>.conf/<MAC>.conf
Specify the return code and the reason of
the SIP response message when refusing a
call.
Local Web User Interface
Specify the return code and the reason of
the SIP response message when refusing a
call.
Navigate to:
http://<phoneIPAddress>/fcgi/do?id=4&id=2
To specify the return code and the reason when refusing a call via web user interface:
1. Click on Phone > Call feature
2. On Others, select the desired value from the pull-down list of Return Code When Refuse
3. Click Submit to accept the change
Early Media
Before a SIP call is established, the phone will play the early media (e.g., audio and video) to
the caller. Current implementation supports early media through the 183 message. When
the caller receives a 183 message with SDP before the call is established, a media channel is
established. This channel is used to provide the early media stream for the caller.

Akuvox SP-R5xP Specifications

General

Brand	Akuvox
Model	SP-R5xP
Category	IP Phone
Language	English
