TIM (Client Ports)
Severity Minor
Service affecting? No
Applicability 112SA1L, 112SCX10, 112SX10L, 11DPE12, 11DPE12E,
11QPA4, 11STAR1, 11STMM10, 11STGE12, 43SCX4, 43STA1P,
43STX4, 43STX4P, 4DPA4
Corrective Action
NOTICE
Service-disruption hazard
A cold reset, reseat, or replacement of a card is service impacting if the card is currently
carrying services. To determine if any services are currently carried over a card, perform
the procedure “Reseating a Card” (p. 3-19).
If
there are services currently carried over the card, it may be best to wait for a
maintenance window before resetting, replacing, or reseating the card.
At the end of each step wait to see if the fault clears. If not, continue with the next step.
...................................................................................................................................................................................................
1
Check that the section trace configuration of the client port is correct:
CLI show interface
card <shelf slot port>
WEBUI From the Equipment Tree, select the card, and select the desired port.
...................................................................................................................................................................................................
2
If there are errors in the provisioned section trace correct them.
CLI config interface
card <shelf slot port>
sectTrace expectedTrace
...................................................................................................................................................................................................
3
Check the SONET device generating the section trace, connected to the client port that is
raising the TIMS alarm, and verify its configuration. If there are errors in the provisioning
of the section trace transmit state, mode or message, correct them. Refer to that device's
user manual.
Trouble-clearing procedures
TIM
TIM (Client Ports)
....................................................................................................................................................................................................................................
....................................................................................................................................................................................................................................
2-322
1830 PSS-36/PSS–32/PSS-16/PSS-4
8DG60888CAAA Release 3.6.0 and 3.6.1
Issue 1 June 2011
