Interfaces
Page 668 7750 SR Interface Configuration Guide
A;ALA-1#
Port Frame Relay Output — The following table describes port Frame Relay output fields.
Sample Output
A:ALA-49>config>port# show port 8/1/2 frame-relay
===============================================================================
Frame Relay Info for 8/1/2
===============================================================================
Mode : dte LMI Type : itu
FR Interface Status : fault
N391 DTE : 6 N392 DCE : 3
N392 DTE : 3 N393 DCE : 4
N393 DTE : 4 T392 DCE : 15
T391 DTE : 10
Tx Status Enquiry : 0 Rx Status Enquiry : 0
Rx Status Messages : 0 Tx Status Messages : 0
Status Message Timeouts : 0 Status Enquiry Timeouts : 0
Discarded Messages : 0 Inv. RxSeqNum Messages : 0
===============================================================================
A:ALA-49>config>port#
Port Frame Relay Output Fields OTU Output — The following table describes the OTU output fields.
Label Description
Mode
Displays the mode of the interface. It can be set as Data terminal
equipment (dte) or Data circuit-terminating equipment (DCE).
LMI Type
Displays the LMI type.
FR Interface
Status
Displays the status of the Frame Relay interface as determined by the
performance of the dlcmi. If no DLCMI is running, the Frame Relay
interface will stay in the running state indefinitely.
Label Description
OTU Status
Status of the OTU (Optical Transport Unit): enabled or disabled. When
OTU is enabled, and additional layer of framing encapsulates an MDA's
natively programmed mode of operation, 10-Gigabit Ethernet LAN or
WAN, adding SONET-Like Framing with FEC (Forward Error Correction).
When OTU is disabled, the MDA operates in a 10-Gigabit Ethernet LAN or
WAN as per Ethernet provisioning.
