Interfaces
Page 710 7750 SR Interface Configuration Guide
MC-Ring Ring-Node Field Output Show MC-Ring Ring-Node Field Output
MC-Ring Global-Sta tistics Field Output Show MC-Ring Global-Statistics Field Output
Label Description
Oper State Displays the state of the connection verification (both local and
remote).
notProvisioned — Connection verification is not provisioned.
configErr — Connection verification is provisioned but a
configuration error prevents it from operating properly.
notTested — Connection verification is administratively
disabled or is not possible in the current situation.
testing — Connection Verification is active, but no results are
yet available.
connected — The ring node is reachable.
disconnected — Connection verification has timed out.
In Use Displays “True” if the ring node is referenced on an e-pipe or as an
inter-dest-id on a static host or dynamic lease.
Label Description
Rx Displays the number of MC-ring signalling packets were received by
this system.
Rx Too Short Displays the number of MC-ring signalling packets were received by
this system that were too short.
Rx Wrong Authen-
tication
Displays the number of MC-ring signalling packets were received by
this system with invalid authentication.
Rx Invalid TLV Displays the number of MC-ring signalling packets were received by
this system with invalid TLV.
Rx Incomplete Displays the number of MC-ring signalling packets were received by
this system that were incomplete.
Rx Unknown Type Displays the number of MC-ring signalling packets were received by
this system that were of unknown type.
Rx Unknown Peer Displays the number of MC-ring signalling packets were received by
this system that were related to an unknown peer.
