Interfaces
Page 722 7750 SR Interface Configuration Guide
Multilink-Bundle Relations Output Fields
Sample Output
A:ALA-48>show# show multilink-bundle bundle-ima-1/1.2 relations
==============================================================================
Bundle Relationship
==============================================================================
Bundle Admin Oper Working Protect Active
Id State State Bundle Id Bundle Id Bundle
------------------------------------------------------------------------------
bpgrp-ima-1 Down Down bundle-ima-1/1.1 bundle-ima-1/1.2 Protect
------------------------------------------------------------------------------
Bundles : 1
==============================================================================
A:ALA-48>show#
ima
Syntax multilink-bundle ima
Context show>multilink-bundle
Description This command enables the context to display IMA group data.
MDA Values 1, 2
Output Show Mutlilink-bundle IMA Connections Output — The following table describes show multilink-
bundle IMA output fields.
Multilink-Bundle IMA Output Fields
Protect BundleID Displays the bundle that is currently in protect mode.
Active Bundle Displays the mode of the active bundle.
Label Description
Label Description
BundleId
Displays the bundle ID number.
Type
Specifies the type of this multilink bundle.
mlppp — Indicates that the bundle is of type MLPPP.
ima — Indicates that the bundle is of type IMA group.
Admin State
ima — Indicates that the bundle is of type IMA group.
Down — The bundle is administratively down.
Oper State
Up — The bundle is operationally up.
Down — The bundle is operationally down.
Port State
Displays the state level of the port.
