Accessories
8AL90399ENAD ed01 121/141
5.5.3.1 Remove the customization kit
A
B
C
1
Slide your fingernail along the
piece to detach it from the
phone.
This piece is clipped to the four
corners. We recommend starting
from the back of the desk phone.
Carefully insert a thin, non-sharp
object over the colored piece on left
side.
Press, then slide the piece
towards the bottom of the
device a few millimeters
with your thumbs.
2
Pull perpendicular to the desk
phone along the entire length
of the piece. Be careful not to
break the clips.
Gently lift the piece by pushing
forward (you will hear a small click
when the piece is removed).
Remove the piece by
lifting it.
Be careful not to break the
clips.
3
Insert the thin, non-sharp object on
the right side.
4
Gently lift the piece by pushing
forward (you will hear a small click
when the piece is removed).
5
Remove the piece by rotating it as
shown in the drawing.
5.5.3.2 Install the customization kit
A
B
C
1
Place each clip facing the
corresponding notches. Be
careful to place the piece in
the correct direction: the logo
must be on the right hand
side.
Insert the piece around the speaker
of the station.
Press as shown in the drawing to clip
the piece in the front (you should
hear a small click when the clip is in
its notch).
Place the piece by
respecting the notches.
2
Press perpendicular to the
desk phone all along the
piece. Press gently so as not
to force and break a clip.
Push the piece by slight rotation until
it is in its place.
Slide the piece to the top
of the hands a few
millimeters with your
thumbs.
3
Press as shown in the drawing to clip
the piece in the back (you should
hear a small click when the clip is in
its notch).
