Accessories
8AL90399ENAD ed01 130/141
First remove the keyboard and add-on if installed.
Use the recommended screws.
Depending on your country (United States), use a standard plate (not provided with the kit).
Put the support on the back side of the desk phone:
1. Place the two bottom support hooks at the top of the connector slot.
2. Use the dedicated screw to fix the supportt (PN: 1AD100020011, Length= 12 mm, Diameter=
14,5 mm).
1. Depending on the case, fix the screws on the wall using the screw anchors or fix the plate
on the wall. To mount your phone on the wall, you need to install a standard wall plate that
you can easily find on the market. Follow the manufacturer's instructions to install the wall
plate on the wall. When the wall plate is fixed, you can prepare your phone and mount it on
the wall.
2. Hang the assembled phone with support on the wall as described in the picture.
