Mounting the Switch Chassis and Power Supplies
page 3-24 OmniSwitch 6465 Hardware Users Guide December 2019
Side Rails, Rear Brackets, and Power Supply Tray with Power Supplies
3 Power Supply Cover.
Power Supply Tray Cover (Power Supplies Not Shown)
Thumb Screws
Filler Bracket
(2) M3X6MM
Slider Brackets
(2) M3X6MM
Cover
(4) M3X6MM
Bottom View
Top View
