Power Supplies Chassis and Power Supplies
page 3-30 OmniSwitch 6465 Hardware Users Guide December 2019
OS6465-BPRD 180W DC Power Supply
Model OS6465-BPRD (PS-I180DC-P)
Description
Modular DC power supply. Up to two (2) power supplies
may be installed.
Dimensions (H x W x L) 5.1 cm x 9.5 cm x 18.1 cm (2 in x 3.74 in x7.12 in)
Weight
1.44 kg (3.17 lbs)
Models Supported OS6465-P28
Input Voltage / Current -20 VDC to -28 VDC / 12A
-36 VDC to -72 VDC/ 6A
Output Voltage / Current -56V/2.5A (140W)
-56V/3.22A (180W)
Status LEDs Solid Green indicates normal operation
Max. Output for PoE Power See “Power over Ethernet Budget”.
Power Supply Front
Power Supply Rear
