Power Supplies Chassis and Power Supplies
page 3-28 OmniSwitch 6465 Hardware Users Guide December 2019
OS6465-BPN AC Power Supply
75W AC Power Supply
LED States
Model OS6465-BPN (PS-I75AC, SDR-75-48)
Models Supported OS6465-P6, OS6465-P12
Input Voltage Range 100 - 240VAC
Input Frequency 47 - 63Hz
Input Current 1.5A
Output Voltage -48VDC
Output Current 1.6A
Output Power 75W
Max. Output for PoE Power See “Power over Ethernet Budget”.
LED State Description
DC OK LED Solid Green DC power is good
DC OK LED Solid Red There is a DC power issue
