Chassis and Power Supplies Power Supplies
OmniSwitch 6465 Hardware Users Guide December 2019 page 3-29
OS6465-BPR Power Supply
Model OS6465-BPR (PS-I180AC-P)
Description Modular AC power supply. Up to two (2) power supplies
may be installed.
Dimensions (H x W x L) 5.1 cm x 9.5 cm x 18.1 cm (2 in x 3.74 in x7.12 in)
Weight 1.36 kg (3.00 lbs)
Models Supported OS6465-P28
Input Voltage / Current / Hz 100 VAC to 240 VAC / 3 A - 1.5 A / 50-60 Hz
Output Voltage / Current +56 VDC / 3.22 A
Status LEDs Solid Green indicates normal operation
Max. Output for PoE Power See “Power over Ethernet Budget”.
Power Supply Front
Power Supply Rear
