OmniSwitch 6900 Hardware Users Guide June 2020 page 1-1
1 OmniSwitch 6900
The OmniSwitch 6900 (OS6900) is a family of aggregation switches that can also be installed as top-of-
rack boxes in data centers. Refer to the information below for model number and
component type.
OS6900 switches provide 1+1 redundant hot-swappable power supplies and a hot-swappable fan tray.
All models include one RJ45 10/100/1000 EMP port, one console connector, one USB 2.0 high speed
(480Mbits/sec) connector and support for front-to-rear or rear-to-front chassis airflow.
Model Number Description
OS6900-X20 Chassis with 20X10G SFP+ ports
OS6900-X40 Chassis with 40X10G SFP+ ports
OS6900-X72 Chassis with 48 fixed auto negotiable 1/10G SFP+ ports and six (6) 40G QSFP+
ports that operate at 40G or 4x1/10G. (Maximum 10G port density is 72
10G ports.)
OS6900-T20 Chassis with 20X10G 10GBase-T ports
OS6900-T40 Chassis with 40X10G 10GBase-T ports
OS6900-Q32 Chassis with 32X40G QSFP+ ports (with specified ports also supporting 40G
or 4X10G)
OS6900-V72 Chassis with 48XSFP28 ports and 6X100G QSFP28 ports
OS6900-C32 Chassis with 32X100G QSFP28 ports
OS6900-T48C6 Chassis with 48X10GBaseT ports and 6X100G QSFP28 ports
OS6900-X48C6 Chassis with 48X10G SFP+ ports and 6X100G QSFP28 ports
OS-XNI-U4 Plug-in module with 4X10G SFP+ ports
OS-XNI-U12 Plug-in module with 12X10G SFP+ ports
OS-XNI-U12E Enhanced plug-in module with 12X10G SFP+ or 12X2G/4G/8G
Fibre Channel ports
OS-QNI-U3 Plug-in module with 3X40G QSFP+ ports
OS-HNI-U6 Plug-in module with 4X10G SFP+ and 2X40G QSFP+ ports
OS-XNI-T8 Plug-in module 8X10G 10GBase-T ports
