Chassis and Power Supplies Power Supplies
OmniSwitch 6900 Hardware Users Guide June 2020 page 3-55
Removing Power Supplies
1 When removing a power supply, first disconnect the power cord from the power source. Once the
power cord is disconnected, pull the power cord out of the power supply housing.
2 Pressing the lock tab toward the right, as shown, will free the power supply from the chassis. While
pressing the lock tab, pull the power supply straight back and out of the chassis slot.
Note. If you are not replacing the power supply, be sure to install a blank cover panel over the empty
power supply bay.
OS6900-V72/C32/X48C6/T48C6 (X48C6/T48C6 shown)
1. Remove power cord.
2. Press the lock tab and remove power supply.
3. Install replacement power supply.
