Chassis and Power Supplies Plug-In Modules
OmniSwitch 6900 Hardware Users Guide June 2020 page 3-45
Removing Plug-In Modules
1 Loosen the captive screw.
2 Pull down on the lock lever to release the plug-in module from the chassis backplane.
3 Using the lock lever as a handle, pull the plug-in module straight back and out of the chassis.
