OmniSwitch 6900 Expansion Modules
OS-XNI-U4
OS-XNI-U12
Item Description
A
Lock Lever and Captive Screw
B
SFP+ Ports
C
Status LEDs
Power Consumption 19W (fully populated)
Item Description
A
Lock Lever and Captive Screw
B
SFP+ Ports
C
Status LEDs
Power Consumption 44W (fully populated)
