OmniSwitch 6900 Chassis Chassis and Power Supplies
page 3-14 OmniSwitch 6900 Hardware Users Guide June 2020
OS6900-Q32 Chassis Specifications
Note. For OS6900-X20 and OS6900-X40 chassis specifications, refer to page 3-4. For OS6900-X72
chassis specifications, refer to page 3-7. For OS6900-T20 and OS6900-T40 chassis specifications, refer to
page 3-10.
1
Fully populated chassis includes fan tray, two power supplies, all expansion plug-in modules and
no transceivers.
2
Maximum power consumption under full L2 traffic load includes fan tray, two power supplies and
transceivers; no expansion plug-in modules.
Chassis Width 43.3 cm (17.06 inches)
Chassis Height 4.4 cm (1.73 inches or 1RU)
Overall Chassis Depth 55.9 cm (22 inches)
OS6900-Q32 Chassis Weight 7.78 kg (17.15 lb)
OS6900-Q32 Chassis Weight (fully populated)
1
10.86 kg (23.95 lb)
Power Supply Bays 2
Maximum number of 40G ports 32
Maximum number of 10G ports (via QSFP+ to splitter cable) 104
Power Consumption
2
312W
Operating Temperature (Tmra)
OS6900-Q32-F (front-to-rear airflow)
OS6900-Q32-R (rear-to-front airflow)
0°C to 45°C (32°F to 113°F)
0°C to 45°C (32°F to 113°F)
Storage Temperature -10°C to 70°C (14°F to 158°F)
Operating Humidity 5% to 95% non-condensing
Storage Humidity 5% to 95% non-condensing
