Chassis and Power Supplies Chassis Fan Tray
OmniSwitch 6900 Hardware Users Guide June 2020 page 3-57
OmniSwitch 6900-V72/C32/T48C6/X48C6 Fan
Model OS6900V-FT-F, Front-to-Rear
OS6900V-FT-R, Rear-to-Front
Product Compatibility OmniSwitch 6900-V72 / C32
Airflow This fan is available in either a front-to-rear or
rear-to-front model.
Note: Do not mix the OS6900-V72/C32 fans with the OS6900-
T48C6/X48C6 fans. The OS6900-V72/C32 fan thumb screw is
in the middle left (shown above).
Model OS6900-T48C6/OS6900-X48C6-FT-F, Front-to-Rear
OS6900-T48C6/OS6900-X48C6-FT-R, Rear-to-Front
Product Compatibility OmniSwitch 6900-T48C6/X48C6
Airflow This fan is available in either a front-to-rear or
rear-to-front model.
Note: Do not mix the OS6900-T48C6/X48C6 fans with the OS6900-
V72/C32 fans. The OS6900-T48C6/X48C6 fan thumb screw is
in the upper right (not shown).
