Alcatel OmniPCX Enterprise
Section - RSI RSI
Maintenance
localhost> set_feature 7100 routing 1
-- host : sent SetFeature 0xd84 on mcdu "7100" (rose-id=3 host=0)
localhost>
localhost> X10 is route_request
Call the RSI, then enter the command route_select X10 followed by the target, fol lowed by 1.
localhost> route_select X10 7000 1
|Invoke: SER_ROUTE_REQUEST (rose-id=5897 host=0)
| cstaSearCrid=117559046=0x701cf06 |
| cstaSearRoid=5897=0x1709 |
| Connection 1 : (call=21,neqt=463,type=TYPE_PROVIDED:4) |
| Connection 2 : (call=0,neqt=0,type=TYPE_NOT_PROVIDED) |
| (L)Device 1 : "7100" |
| (PRIVATE) (L)Device 2 : "7002" |
| cstaSearFilt=0x00000000 0x00000000 |
| Feature : ident=0 invoke=0 val1=0 val2=0 |
localhost>
host : sent route select on Xref 117559046 (rose-id=7 host=0)
If the target is a ccessible, the ROUTE_EN D_REQUEST information is returned.
lo
calhost>
In
voke: SER_ROUTE_END_REQUEST (rose-id=5898 host=0)
|cs
taSearCrid=117559046=0x701cf06 |
|cs
taSearRoid=5898=0x170a |
|Co
nnection 1 : (call=0,neqt=0,type=TYPE_NOT_PROVIDED) |
|Co
nnection 2 : (call=0,neqt=0,type=TYPE_NOT_PROVIDED) |
| (L)
Device 1 : ABSENT |
| (L)
Device 2 : ABSENT |
| cst
aSearFilt=0x00000000 0x00000000 |
| Fea
ture : ident=0 invoke=0 val1=0 val2=0 |
2.2. ccdn
The command ccdn is used to check:
- Monitoring (Monitor) of the RSI (identified when monitored by the letter T)byoneormore
Tservers (a n RSI can be monitored by several TServers)
- Activation (Enable) of the RSI (identified when enab led by the letter T) b y a TServer (an RSI can
only be enabled by a single TServer).
Enter the command ccdn -d followed by the RSI numb er.
localhost>ccdn —d 7100
--------------------------------------------------------------------------------------
| Addres : 7100 |Lognum : 0 |
--------------------------------------------------------------------------------------
| Name : RSI | Type : Local | Prefix : | Node : 7 |
--------------------------------------------------------------------------------------
| Exploitation Category : 0 | Connection Category : 0 |
| External Category : 0 | Taxation Category : Justified|
| Transactation Code Dial. Timer : 100 | Language : 1 |
| Hold on guide number : 2 | Wrap Up Time : 6000 |
| Overflow Time Out : 150 | Overflow Address : |
| Cost Center : 255 | Pause Time : 50 |
Ed.03 Ref.3EU19 919ENAA .41
