Alcatel OmniPCX Enterprise
RSI Section - RSI
Architecture
2. RSI architecture integrating an SSBD
A Two-Way Synchroni zation Server or SSBD c an be added to the previous basic configuration. The
SSBD is a P C application operating in a Windows 2000 environment. Its role is to synchronize the
OmniPCX Enterprise RSI objects with those of the G enesys suit e.
The SSBD is connecte d to the Genesys suite and the OmniPCX Enterprise via the following interfaces:
- ACAPI (Alcatel Configuration Program Interface), which allows the OmniPCX Enterprise RSI
objects to be extracted and then trasmitted t o the Genesys s uite for synchronization.
- CFGLIB, whic h allows the Genes ys suite RSI objects to be extracted and then transmitted to the
OmniPCX Enterprise for synchronization.
As for the other Genesys suite servers, the SSBD also uses the following interfaces for correct operation:
- SCI (Solution Control Interface), which controls the interface from which the SSBD is started
and stopped
- SCS (Solution Control Server), whi ch sends a start or stop request to the LCA with the SSBD
parameters
- LCA (Local Control Agent), which starts or stops the SSBD using the param eters prov ided by the
SCS.
Figure 1 : SSBD architecture
Config Server
Genesys suite
OmniPCX
Enterprise
RSI
Tserver
SCI
SCS
LCA
Genesys suite
SSBD
CFGLIB
ACAPI
Synchro Server
.6 Ref.3EU19919ENAA Ed.03

Alcatel OmniPCX Enterprise Specifications

General

System Type	IP PBX
VoIP Protocols	SIP, H.323
Voice Codecs	G.711, G.729
Networking	IP
Redundancy	Yes
Unified Communications	Yes
Integrated Applications	Voicemail, Conferencing
Network Interfaces	Ethernet
Humidity	10% non-condensing
