Alderon Industries™ - Leading Edge Control Products | 3
Mini Power Post™ Monitoring System - USER GUIDE
Introduction
Use the Mini Power Post™ Monitoring System to make a professional and safe connection for power and oat switch wiring
connections to your on-site septic system. The Mini Power Post™ eliminates a 4" x 4" wood post and the exposed wires for a
safe, clean, and quick installation. This system can be used for a wide variety of demand dose applications, including but not
limited to: septic tanks, holding tanks, pump chambers, and water tanks. Available models include 120VAC and 240VAC.
The Mini Power Post™ Monitoring System serves as a junction box equipped with LED indicators (various colors) which is
connected to a remote alarm panel. The top of the enclosure cover changes color along with system function displayed text
on the OLED screen for easy troubleshooting information. Menu keys are provided to program settings and view data such as:
pump cycle counts, pump amps, elapsed time, total gallons pumped, alarm conditions, and more.
The system can be equipped with a Versa’larm™ alarm panel to connect a high level alarm oat switch, and/or lter switch
for remote notication of high level and lter service alarm conditions. A customer supplied sensor wire is used to make the
connections between the terminals on the remote alarm panel and the Mini Power Post™ enclosure.
Safety Guidelines
Before proceeding with the installation or operation of this product, read all instructions thoroughly, as well as complying with
all federal, state and local codes, regulations, and practices. This product must be installed by qualied personnel familiar with
all applicable local electrical and mechanical codes. Refer to the National Electrical Code (NFPA 70). Failure to properly install
and test this product can result in personal injury or equipment malfunction.
WARNING
1. DISCONNECT POWER when installing or servicing the product. Failure to disconnect all power sources could result in
serious injury or death.
2. NEVER enter a ooded space without proper Personal Protective Equipment (PPE). Always wear dielectric rubber boots
and other applicable protective equipment when water is on the oor and you must service an energized pump, alarm
system, or product.
3. DO NOT enter the water if the water level is higher than that of the protection your PPE offers or if your PPE is not
watertight.
4. DO NOT use this product with or near ammable liquids.
5. DO NOT install this product in locations classied as hazardous or in explosive atmospheres as dened by any applicable
electrical safety code.
System Guidelines
CAUTION: Before proceeding with the operation of this product, Alderon™ recommends changing the factory settings to
customize the system per application for desired operation. See page 21 for complete system settings information.
1. EXTENDED PUMP RUN TIME - Allowable time for pump to run continuously for longer than congured amount of time.
2. HIGH AMP LEVEL - Acceptable level of current sensed on the pump input during a pump run event.
3. GALLONS PER MINUTE - Perform manual test to determine value entered, when set to zero no statistics are displayed.
