4 | Alderon Industries™ - Leading Edge Control Products
Mini Power Post™ Monitoring System - USER GUIDE
Product Included
This model includes: (1) Mini Power Post™ Monitoring System, (1) Pump Power Receptacle (120VAC or 240VAC, voltage
depends on model/part number), and (6) Wago connectors.
(1) Mini Power Post™ Monitoring System
The Mini Power Post™ comes with a 42.5-inch post to install in
the ground. The ventilated post cap, cable grips, and junction
box are all pre-installed to the post.
(2) Pump Power Receptacle
A female power receptacle is pre-installed, rated at 15 Amps.
Available in 120VAC or 240VAC models.
(3) Wago Connector
Six Wago connectors are included. Three are pre-installed on
the pump power receptacle and three are loose in enclosure, all
used for making wire terminations.
ADDITIONAL OPTIONS:
(4) Versa’larm™ Indoor Alarm Panel
The Versa’larm™ indoor alarm panel has options for remote
monitoring of one or two zones (sensors).
(5) Alarm Float Switch
The alarm oat switch is a typical sensor expected to be used
with the Versa’larm™ indoor alarm for liquid level monitoring.
(6) Pump Float Switch
The pump oat switch is used to control the pump directly. When
actuated the pump oat switch will pass power to the pump.
(7) Filter Switch
The lter switch is a typical sensor expected to be used with the
Versa’larm™ indoor alarm. The lter switch is used to activate
an alarm when a septic tank efuent lter needs to be serviced
and is universal to any brand of efuent lter that has a one-inch
through hole.
3
(120VAC Model Shown)
21
6
5
4 7
