ARTIX-7 FPGA Development Board AX7035 User Manual
Supports up to 1080P@60Hz output and supports data output in
different formats
1-channel HDMI image video input interface
Supports up to 720P@60Hz input and supports data input in different
formats
1-channel high speed USB2.0 interface
Using FT232H single-channel USB chip of FTDI, it can be used for
USB2.0 high-speed communication between development board and
PC, with a maximum speed of 480Mb/s.
1-channel USB Uart interface
1-channel Uart to USB interface for communication with the computer
for user debugging. The serial port chip adopts the USB-UAR chip of
Silicon LabsCP2102GM, and the USB interface adopts the MINI USB
interface.
Micro SD slot
1-channel Micro SDslot, supports SD mode and SPI mode.
A 6-digit digital tube that dynamically displays 6 digits.
Temperature and humidity sensor
Onboard a temperature and humidity sensor chip LM75 for detecting
the temperature and humidity of the environment around the board
2-channel40-pin expansion port
Reserve 2 40-pin 2.54mm pitch expansion ports, which can be
connected to various ALINX modules (binocular camera, TFT LCD
screen, high-speed AD module, etc.). The expansion port contains 1
channel 5V power supply, 2 channel 3.3V power supply, 3 way ground,
34 IOs port.
1-channel FPC expansion port
A 15-pin FPC expansion port is reserved for connecting the user's MIPI
camera module.
