Part 18: FPC Expansion Ports
A 15-pin FPC expansion port J8 is reserved on the AX7035 FPGA
development board, and an external module (such as a MIPI camera) is
connected through a 15-line 1mm pitch FPC cable. The expansion port has 3
pairs of differential signals, 4 control signals, 1-channel 3.3V power supply
(output), and 4-channel ground. The circuit of the FPC expansion port (J8) is as
shown in Figure 18-1.
