Reset Mix Settings: Standard –
Processing type Setting
48v All off
Preamp gains +28dB
HPFs Out/100Hz
Gates Out/-30dB
Inserts Out
PEQs In/Flat
GEQs In/Flat
Compressors Out/3:1/-9dB
Pans Centred
Control Setting
SoftKeys 1-6
Mute Groups 1 to 6
SoftKey 7 Unassigned
SoftKey 8 Global Tap Tempo
SoftKeys 9-16 Unassigned
SoftRotaries Unassigned
Master Fader Mode Mix Master
FX unit Setting
1 EMT 250 reverb/FX1Snd/FX1Rtn
2 Hall 480 reverb/FX2Snd/FX2Rtn
3
Stereo Tap Vocal Delay/FX3Snd/FX3Rtn
4 ADT Classic/FX4Snd/FX4Rtn
5-8 Empty/Unpatched
Send type Level
Input channels -inf
FX return channels 0dB
Main LR master 0dB
Aux master 0dB
Group master -inf
FX master 0dB
Routing Setting
Input Stereo
40 mono (1-40), 4 stereo (ST1, ST2, ST3, USB)
Local Input patching
1-to-1 (as labelled), then unassigned to 46
Mix Bus Configuration
Aux 1-4 (mono), Aux 5-8 (stereo), Group 9-12 (Stereo)
LR Assign All inputs and groups assigned
Aux assign and send Inputs to all Aux, Pre-Fade, Post-EQ
Local Output patching (Aux) 1-to-1 for mono then sequential stereo
Local Output patching (Main) 11 (Main L) & 12 (Main R)
Local Output patching (Matrix 1) A & B
AES output Main LR
Remote Audio Unit Inputs Unassigned
Remote Audio Unit Outputs Unassigned
SQ to USB Main LR on 1 & 2, then 1-to-1 direct out
USB to SQ USB 1 & 2 to input channels 47 & 48
