Reset Mix Settings: Monitor –
Processing type Setting
48v All off
Preamp gains +28dB
HPFs Out/100Hz
Gates Out/-30dB
Inserts Out
PEQs In/Flat
GEQs In/Flat
Compressors Out/3:1/-9dB
Pans Centred
Control Setting
SoftKeys 1-8 Mute Groups 1 to 8
SoftKeys 9-16 Unassigned
SoftRotaries Unassigned
Master Fader Mode Listen Level
FX unit Setting
1-4 EMT 250 reverb/FXSnd 1-4/FXRtn 1-4
5-8 Empty/Unpatched
Send type Level
Input channels 0dB
FX return channels 0dB
Main LR master 0dB
Aux master 0dB
Group master -inf
FX master 0dB
Routing Setting
Input Stereo 48 mono (1-48)
Local Input patching 1-to-1 (as labelled), then unassigned to 48
Mix Bus Configuration Aux 1-6 (mono), Aux 7-12 (stereo)
LR Assign All inputs unassigned
Aux assign and send Inputs to all Aux, Post-Fade, Post-Delay
Local Output patching (Aux) 1-to-1 for mono then sequential stereo
Local Output patching (Listen M) 12
Local Output patching (PAFL) A & B
AES output Main LR
Remote Audio Unit Inputs Unassigned
Remote Audio Unit Outputs Mixes 1-to-1, then Main LR on last 2 sockets.
SQ to USB Unassigned
USB to SQ Unassigned
