Serial Communications
B-7
Table B.4 Parameter Grouping/User Settings
(continued)
Group Parameter Name
Parameter
Number
Display
Units
Drive Units
Scale Factor
Minimum Maximum Factory Setting
User‘s
Setting
Minimum Freq 16 Hz 1 0 120 0
Maximum Freq 19 Hz 1 40 400 60
Base Frequency 17 Hz 1 40 400 60
Base Voltage 18 Volts 1 25% of DRV 100% of Max. Drive Rated Volts Maximum DRV
Break Frequency 49 Hz 1 0 120 30
p
Break Voltage 50 Volts 1 0 50% of Max Drive Rated Volts Drive Size
Dependent
t
Up
Maximum Voltage 20 Volts 1 25% of DRV 110% of Max. Drive Rated Volts Maximum DRV
Set
DC Boost Select 9 Text 1 –– –– Break Point
a
nced
S
Start Boost 48 Volts 1 0 25% of Max. Drive Rated Volts Drive Size
Dependent
d
va
n
Run Boost 83 Volts 1 0 25% of Max. Drive Rated Volt 0
Ad
v
PWM Frequency 45 kHz 10 2.0 8.0 4.0
Analog Invert 84 Text 1 –– –– Disabled
4–20 mA Loss Sel 81 Text 1 –– –– Stop/Fault
Stop Select 10 Text 1 –– –– Ramp
DC Hold Time 12 Seconds 100 0.0 150.0 0.0
DC HoId Volts 13 Volts 1 0 25% of Max. Drive Rated Volts 0
DB Enable 11 Text 1 –– –– Disabled
Motor Type 41 Text 1 –– –– Induc/Reluc
Compensation 52 Text 1 –– –– Comp
Refer to Table B.1 on pages B-13, B-14 and B-15 for the numerical equivalent of the text descriptions.
Refer to page B-2.
