Allen-Bradley 1305 Series User Manual

Serial Communications
B-8
Table B.4 Parameter Grouping/User Settings
(continued)
Group Parameter Name
Parameter
Number
Display
Units
Drive Units
Scale Factor ➁
Minimum Maximum Factory Setting
User’s
Setting
Freq Select 1 5 Text ➀ 1 –– –– Adapter 1
Freq Select 2 6 Text ➀ 1 –– ––– Remote Pot
Jog Frequency 24 Hz 100 0.0 400.0 10.0
Prst/2nd Accel 26 Text ➀ 1 –– –– Preset
Upper Presets 72 Text ➀ 1 –– –– Disabled
Accel Time 2 30 Seconds 10 0.0 3600.0 5.0
Decel Time 2 31 Seconds 10 0.0 3600.0 5.0
S
et
Preset Freq 1 27 Hz 100 0.0 400.0 10.0
c
y
S
Preset Freq 2 28 Hz 100 0.0 400.0 20.0
u
enc
Preset Freq 3 29 Hz 100 0.0 400.0 30.0
e
qu
e
Preset Freq 4 73 Hz 100 0.0 400.0 40.0
Fre
q
Preset Freq 5 74 Hz 100 0.0 400.0 50.0
F
Preset Freq 6 75 Hz 100 0.0 400.0 60.0
Preset Freq 7 76 Hz 100 0.0 400.0 0.0
Skip Freq 1 32 Hz 1 0 400 400
Skip Freq 2 33 Hz 1 0 400 400
Skip Freq 3 34 Hz 1 0 400 400
Skip Freq Band 35 Hz 1 0 15 0
MOP Increment 22 Hz/Second 1 0.00 255.00 1.00
Analog Filter 144 Text ➀ 1 –– –– 100%
➀ Refer to Table B.7 on pages B-13, B-14 and B-15 for the numerical equivalent of the text descriptions.
➁ Refer to page B-2.
