❑ 10. INPUT MODE SELECTION (continued)
a.) From the Status Display, press the Enter key (or any key). ‘‘Choose
Mode” will be displayed.
b.) Press the Increment (or Decrement) key until ‘‘Program” is displayed.
c.) Press Enter. The parameter group ‘‘Metering” will be displayed.
d.) Press the Increment key again until the ‘‘Set Up” Group is displayed.
e.) Press Enter.
f.) Press the Increment or Decrement key until the [Input Mode]
parameter is displayed.
g.) Press SEL. The first character of line 2 will now flash.
h.) Press the Increment or Decrement key until the correct mode is
displayed, then press enter. The first character of line 1 should now be
flashing.
i.) Press the ESC key (3 times) to return to the Status Display.
Important: If the [Input Mode] is changed, power must be cycled for the
change to take effect.
Choose Mode
Program
Choose Mode
Display
Choose Group
Set Up
Input Mode
Run Fwd/Rev
Stopped
+0.00 Hz
Input Mode
3 Wire
Input Mode
3 Wire
Choose Group
Metering
